Ormig 30 iE

Preço

Preço s/ consulta

Images2
Ormig 30 iE Outras gruas
Ormig 30 iE Outras gruas
FavoriteFavorito
sharePartilhar
Save searchGuardar pesquisa
Imprimir

INFO

Linha de produto
Outras gruas
Marca / modelo
Ormig 30 iE
Ano
2020
Horas de utilização
1 h
Condição
Novo/Nunca usado
País
Italy
Mascus ID
E5FA91F3

DETALHES

N°. de ref. de armazém
000187
Condições de entrega
EXW
Outras informaçőes
Lifting capacity: at 1 m from front plate DIN 30t SAE 33t Front drive Electric motor: 2 da 15 kW Hydraulic and services motor: 25 kW Power source: 96 Volt 1240 Ah Boom height: 12m Working outreach: 8m Road certification Weight: 19 ton BASE MACHINE composed of: ORMIG frame - 4x2 traction. N. 2 electric motors, for translation from about 15 kW, 96 V, with electronic control to allow steering on the machine axis. Fixed front engine axle composed of two independent wheel groups with electronic differential - Steering rear axle No. 4 cushion twin wheels on the front axle and n. 2 cushion wheels on the rear axle 854 320 600 Side-mounted driver's cab, closed, designed and built to allow the operator maximum visibility, digital instrumentation, anatomic and adjustable seat, control of hydraulic movements by means of multiple electronic lever with device against accidental operation, rear-view mirrors, windshield wipers Hydraulic arm with three sections, extraction obtained through n. 2 double-acting hydraulic cylinders - double-acting hydraulic cylinder for lifting the arm. Hydraulic winch with automatic brake, complete with rope, end stop and hook with block. Electrical system approved for road circulation complete with headlights, rear lights and rotating lights. Hydraulic system powered by a variable displacement pump, capacity 340 l, connected to the electric motor to c.a. from 25 kW Lead acid accumulators, voltage 96V, capacity 1240A / h Brakes in compliance with EEC standards, service brake with servo assisted pedal control, mechanical spring-applied parking brake acting on the front wheels with control via electric selector Electronic anti-tipping device with locking of the functions that increase the danger situations according to the directives in force Weight in transport position around 19.800 kg Accessories.Mostrar mais

Ikran Srl

Via Donatori di Sangue, 42 25020 San Paolo Brescia Italy
