CAT CAT305.5E2

Preço

Images10
CAT CAT305.5E2 Miniescavadeiras
CAT CAT305.5E2 Miniescavadeiras
CAT CAT305.5E2 Miniescavadeiras
FavoriteFavorito
sharePartilhar
Save searchGuardar pesquisa
Imprimir

INFO

Linha de produto
Miniescavadeiras
Marca / modelo
CAT CAT305.5E2
Ano
2024
Horas de utilização
450 h
Condição
Remanufactured
País
China
Grau geral
1
2
3
4
5
Mascus ID
77BC2619

PREÇO

Escolha a moeda

DETALHES

Tipo de accionamento
Diesel
Histórico de serviço completo
Sim
Número de proprietários anteriores
1
Condição do chassi
good
Peso bruto
5.500 kg
Classe de emissăo
Stage V
Largura Rastro
400 mm
Capacidade do balde
0,22 m3
Dimensőes em transporte (CxLxA)
576519502.54 m
Cor Original
YELLOW
Dipper / stick length
960 mm
Motor
Cat C2.4 DI
Potência do motor
34,1 kW (46,4 cv)
Fabricante do Motor
JAPAN
Informações de condição/garantia
good
País de fabrico
Japan
Condições de entrega
FOB, CIF, EXW
Certificados
EPA, CE, ANSI, AS, CSA, EAC GOST, TRUA, JIS, TÜV, ASME
Implementos
All the auxiliary accessories can be provided for you. The above information is for reference only, and the specific details need to be confirmed with the factory.
Acessórios
caixa fios twig
Air conditioning
Equipamento hidráulico adicional
Ad blue
Mostrar mais
Outras informaçőes
The performance parameters of the Caterpillar CAT305.5E2 excavator are as follows: 1. **Overall Dimensions of the Machine** - Total transportation length: 5765mm, total transportation width: 1950mm, total transportation height: 2540mm, minimum ground clearance: 628mm, rear swing radius: 1580mm, total track length: 2440mm, track gauge: 1550mm, track shoe width: 400mm, center distance between idler wheels: 1920mm. 2. **Operating Weight** - The operating weight of the whole machine is 5400kg. 3. **Bucket Capacity** - The bucket capacity is 0.22 cubic meters. 4. **Power System** - Engine model: Cat C2.4 DI, rated power: 34.1kW, cylinder bore: 87mm, stroke: 102.4mm, displacement: 2.4L. 5. **Performance Parameters** - Swing speed: 10.5rpm. - Gradability: 50%. - Bucket digging force: 35.0kN. - Stick digging force: 27.2kN. - Maximum drawbar pull: 40.2kN. - Travel speed: 4.3/2.8km/h. - Swing torque: 13.9N·m. 6. **Hydraulic System** - Maximum main pump flow: 140L/min. The type of the main pump is a load sensing hydraulic system equipped with a variable displacement piston pump, and the working hydraulic circuit pressure is 25MPa. 7. **Oil Capacity** - Fuel tank: 78L, hydraulic oil tank: 58L, engine oil change capacity: 9.5L, coolant: 9.8L. 8. **Working Range** - Maximum digging radius: 5955mm. - Maximum digging depth: 3720mm. - Maximum digging height: 5460mm. - Maximum unloading height: 3835mm. - Maximum vertical digging depth: 2210mm. 9. **Bulldozer Blade Parameters** - Lifting or pushing depth: 365mm/480mm, width×height of the bulldozer blade: 1950mm×360mm.Mostrar mais

Shanghai FanChi Machinery trading Co., LTD

hongmei Road 200000 Minhang Shanghai 上海 China
